GMR MAGNETIC REST
Specifiche Tecniche / Technical Specifications
- RH Version model: GMR-98 / LH Version model: GMR-99
- Assembled as Vertical resistance adjustable rest
- Can be converted to Drop Away rest by the special Brass magnet holder provided
- Aluminum Black anodized body
- Super power Neodymium magnets operation
- Suitable for Recurve risers from 12 to 16 mm window thickness and 2 plungers holes
- 3D printed plastic color cover to protect inner mechanism from rain and dirt
- Tested for use of any kind of arrow up to 23xx Aluminum with 220 gr point
- Compatible to all GILLO Risers, fits perfectly the shape of GF risers
- Approx. 36 g mass weight only
Packing includes:
- Black and Yellow Plastic 3D printed covers
- Brass M8 x 1 threaded Brass screw holder with 6 x 5 mm Neodymium magnet, to convert rest to Drop Away function
- 2 Allen wrenches – 2 mm and 2.5 mm
- 1 x 5/16-24 x 5/8” Stainless steel Cup head screw with 1 x M8 Stainless steel washer
- 1 x longer rest wire
- 1 x M4 x 8 mm Stainless Steel grub screw for additional tuning range
- Basic instruction manual with QR code to download its full version in PDF format
Optional accessories available:
- GMR-98-PC Plastic Covers of different colors
- GMR-98-/99-SW Arm wires of different lengths
